Attention Quantization

Overview

This quantization method quantizes q, k, and v to 8-bit values, reducing the graphics memory usage of the KV cache, optimizing the speed of the attention operator in the decode phase, and improving throughput.

Directory structure of quantized weights after attention and W8A8 quantization:

├─ config.json
├─ quant_model_weight_w8a8.safetensors
├─ quant_model_description.json
├─ tokenizer_config.json
├─ tokenizer.json
└─ tokenizer.model

• The quantized output contains the weight file quant_model_weight_w8a8.safetensors and the weight description file quant_model_description.json.
• The other files in the directory are required for inference, and they vary slightly by model.

The following is a partial view of quant_model_description.json after quantization:

{
  "model_quant_type": "W8A8",
  "fa_quant_type": "FAQuant",
  "model.embed_tokens.weight": "FLOAT",
  "model.layers.0.self_attn.q_proj.weight": "W8A8",
  "model.layers.0.self_attn.q_proj.input_scale": "W8A8",
  "model.layers.0.self_attn.q_proj.input_offset": "W8A8",
  "model.layers.0.self_attn.q_proj.quant_bias": "W8A8",
  "model.layers.0.self_attn.q_proj.deq_scale": "W8A8",
  "model.layers.0.self_attn.k_proj.weight": "W8A8",
  "model.layers.0.self_attn.k_proj.input_scale": "W8A8",
  "model.layers.0.self_attn.k_proj.input_offset": "W8A8",
  "model.layers.0.self_attn.k_proj.quant_bias": "W8A8",
  "model.layers.0.self_attn.k_proj.deq_scale": "W8A8",
  "model.layers.0.self_attn.v_proj.weight": "W8A8",
  "model.layers.0.self_attn.v_proj.input_scale": "W8A8",
  "model.layers.0.self_attn.v_proj.input_offset": "W8A8",
  "model.layers.0.self_attn.v_proj.quant_bias": "W8A8",
  "model.layers.0.self_attn.v_proj.deq_scale": "W8A8",
  "model.layers.0.self_attn.o_proj.weight": "W8A8",
  "model.layers.0.self_attn.o_proj.input_scale": "W8A8",
  "model.layers.0.self_attn.o_proj.input_offset": "W8A8",
  "model.layers.0.self_attn.o_proj.quant_bias": "W8A8",
  "model.layers.0.self_attn.o_proj.deq_scale": "W8A8"

}

Compared with the W8A8 weight quantization, description field fa_quant_type as well as field self_attn and its content are added. input_scale is used to quantize the q, k, and v features to the INT8 type, and deq_scale is used to dequantize the q, k, and v output to the floating-point type.

Figure 1 Inference process for quantizing weights

Table 1 dtype and shape information after float16 weight quantization (assuming that shape of the original weight is [n, k])

Table 2 dtype and shape information after bfloat16 weight quantization (assuming that shape of the original weight is [n, k])
