aclnnBatchNormReduceBackward

Atlas 训练系列产品支持该算子。

Atlas A2训练系列产品支持该算子。

接口原型

每个算子有两段接口，必须先调用“aclnnXxxGetWorkspaceSize”接口获取入参并根据计算流程计算所需workspace大小，再调用“aclnnXxx”接口执行计算。两段式接口如下：

功能描述

aclnnBatchNormReduceBackwardGetWorkspaceSize

aclnnBatchNormReduceBackward

调用示例

  1
  2
  3
  4
  5
  6
  7
  8
  9
 10
 11
 12
 13
 14
 15
 16
 17
 18
 19
 20
 21
 22
 23
 24
 25
 26
 27
 28
 29
 30
 31
 32
 33
 34
 35
 36
 37
 38
 39
 40
 41
 42
 43
 44
 45
 46
 47
 48
 49
 50
 51
 52
 53
 54
 55
 56
 57
 58
 59
 60
 61
 62
 63
 64
 65
 66
 67
 68
 69
 70
 71
 72
 73
 74
 75
 76
 77
 78
 79
 80
 81
 82
 83
 84
 85
 86
 87
 88
 89
 90
 91
 92
 93
 94
 95
 96
 97
 98
 99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
160
161
162
163
164
165
166
167
168
169
170
171
172
173
174
175
176
177
178
179
180
181
182
183
184
185
186
187
188
189
190
191
192
193
194
195

#include <iostream>
#include <vector>
#include "acl/acl.h"
#include "aclnnop/aclnn_batch_norm_backward_reduce.h"

#define CHECK_RET(cond, return_expr) \
  do {                               \
    if (!(cond)) {                   \
      return_expr;                   \
    }                                \
  } while (0)

#define LOG_PRINT(message, ...)     \
  do {                              \
    printf(message, ##__VA_ARGS__); \
  } while (0)

int64_t GetShapeSize(const std::vector<int64_t>& shape) {
  int64_t shape_size = 1;
  for (auto i : shape) {
    shape_size *= i;
  }
  return shape_size;
}

void PrintOutResult(std::vector<int64_t> &shape, void** deviceAddr) {
  auto size = GetShapeSize(shape);
  std::vector<float> resultData(size, 0);
  auto ret = aclrtMemcpy(resultData.data(), resultData.size() * sizeof(resultData[0]),
                         *deviceAddr, size * sizeof(float), ACL_MEMCPY_DEVICE_TO_HOST);
  CHECK_RET(ret == ACL_SUCCESS, LOG_PRINT("copy result from device to host failed. ERROR: %d\n", ret); return);
  for (int64_t i = 0; i < size; i++) {
    LOG_PRINT("result[%ld] is: %f\n", i, resultData[i]);
  }
}


int Init(int32_t deviceId, aclrtContext* context, aclrtStream* stream) {
  // 固定写法，AscendCL初始化
  auto ret = aclInit(nullptr);
  CHECK_RET(ret == ACL_SUCCESS, LOG_PRINT("aclInit failed. ERROR: %d\n", ret); return ret);
  ret = aclrtSetDevice(deviceId);
  CHECK_RET(ret == ACL_SUCCESS, LOG_PRINT("aclrtSetDevice failed. ERROR: %d\n", ret); return ret);
  ret = aclrtCreateContext(context, deviceId);
  CHECK_RET(ret == ACL_SUCCESS, LOG_PRINT("aclrtCreateContext failed. ERROR: %d\n", ret); return ret);
  ret = aclrtSetCurrentContext(*context);
  CHECK_RET(ret == ACL_SUCCESS, LOG_PRINT("aclrtSetCurrentContext failed. ERROR: %d\n", ret); return ret);
  ret = aclrtCreateStream(stream);
  CHECK_RET(ret == ACL_SUCCESS, LOG_PRINT("aclrtCreateStream failed. ERROR: %d\n", ret); return ret);
  return 0;
}

template <typename T>
int CreateAclTensor(const std::vector<T>& hostData,
                    const std::vector<int64_t>& shape,
					void** deviceAddr,
                    aclDataType dataType,
					aclTensor** tensor) {
  auto size = GetShapeSize(shape) * sizeof(T);

  // 调用aclrtMalloc申请device侧内存
  auto ret = aclrtMalloc(deviceAddr, size, ACL_MEM_MALLOC_HUGE_FIRST);
  CHECK_RET(ret == ACL_SUCCESS, LOG_PRINT("aclrtMalloc failed. ERROR: %d\n", ret); return ret);

  // 调用aclrtMemcpy将Host侧数据拷贝到device侧内存上
  ret = aclrtMemcpy(*deviceAddr, size, hostData.data(), size, ACL_MEMCPY_HOST_TO_DEVICE);
  CHECK_RET(ret == ACL_SUCCESS, LOG_PRINT("aclrtMemcpy failed. ERROR: %d\n", ret); return ret);

  // 计算连续tensor的strides
  std::vector<int64_t> strides(shape.size(), 1);
  for (int64_t i = shape.size() - 2; i >= 0; i--) {
    strides[i] = shape[i + 1] * strides[i + 1];
  }

  // 调用aclCreateTensor接口创建aclTensor
  *tensor = aclCreateTensor(shape.data(), shape.size(), dataType, strides.data(), 0, aclFormat::ACL_FORMAT_ND,
                            shape.data(), shape.size(), *deviceAddr);
  return 0;
}

int main() {
  // 1. （固定写法）device/context/stream初始化, 参考AscendCL对外接口列表
  // 根据自己的实际device填写deviceId
  int32_t deviceId = 0;
  aclrtContext context;
  aclrtStream stream;
  auto ret = Init(deviceId, &context, &stream);
  CHECK_RET(ret == 0, LOG_PRINT("Init acl failed. ERROR: %d\n", ret); return ret);  // check根据自己的需要处理

  // 2. 构造输入与输出，需要根据API的接口自定义构造
  std::vector<int64_t> gradOutShape = {4, 2};
  std::vector<int64_t> inputShape = {4, 2};
  std::vector<int64_t> meanShape = {2};
  std::vector<int64_t> invstdShape = {2};
  std::vector<int64_t> weightShape = {2};
  std::vector<int64_t> sumDyShape = {2};
  std::vector<int64_t> sumDyXmuShape = {2};
  std::vector<int64_t> gradWeightShape = {2};
  std::vector<int64_t> gradBiasShape = {2};

  void* inputDeviceAddr = nullptr;
  void* gradOutDeviceAddr = nullptr;
  void* meanDeviceAddr = nullptr;
  void* invstdDeviceAddr = nullptr;
  void* weightDeviceAddr = nullptr;
  void* sumDyDeviceAddr = nullptr;
  void* sumDyXmuDeviceAddr = nullptr;
  void* gradWeightDeviceAddr = nullptr;
  void* gradBiasDeviceAddr = nullptr;
  aclTensor* input = nullptr;
  aclTensor* gradOut = nullptr;
  aclTensor* mean = nullptr;
  aclTensor* invstd = nullptr;
  aclTensor* weight = nullptr;
  aclTensor* sumDy = nullptr;
  aclTensor* sumDyXmu = nullptr;
  aclTensor* gradWeight = nullptr;
  aclTensor* gradBias = nullptr;

  std::vector<float> gradOutHostData = {1, 1, 1, 2, 2, 2, 3, 3};
  std::vector<float> inputHostData = {0, 1, 2, 3, 4, 5, 6, 7};
  std::vector<float> meanHostData = {1, 1};
  std::vector<float> invstdHostData = {1, 1};
  std::vector<float> weightHostData = {1, 1};
  std::vector<float> sumDyHostData = {1, 1};
  std::vector<float> sumDyXmuHostData = {1, 1};
  std::vector<float> gradWeightHostData = {1, 1};
  std::vector<float> gradBiasHostData = {1, 1};

  ret = CreateAclTensor(gradOutHostData, gradOutShape, &gradOutDeviceAddr, aclDataType::ACL_FLOAT, &gradOut);
  CHECK_RET(ret == ACL_SUCCESS, return ret);
  ret = CreateAclTensor(inputHostData, inputShape, &inputDeviceAddr, aclDataType::ACL_FLOAT, &input);
  CHECK_RET(ret == ACL_SUCCESS, return ret);
  ret = CreateAclTensor(meanHostData, meanShape, &meanDeviceAddr, aclDataType::ACL_FLOAT, &mean);
  CHECK_RET(ret == ACL_SUCCESS, return ret);
  ret = CreateAclTensor(invstdHostData, invstdShape, &invstdDeviceAddr, aclDataType::ACL_FLOAT, &invstd);
  CHECK_RET(ret == ACL_SUCCESS, return ret);
  ret = CreateAclTensor(weightHostData, weightShape, &weightDeviceAddr, aclDataType::ACL_FLOAT, &weight);
  CHECK_RET(ret == ACL_SUCCESS, return ret);

  bool inputG = true;
  bool weightG = true;
  bool biasG = true;

  ret = CreateAclTensor(sumDyHostData, sumDyShape, &sumDyDeviceAddr, aclDataType::ACL_FLOAT, &sumDy);
  CHECK_RET(ret == ACL_SUCCESS, return ret);
  ret = CreateAclTensor(sumDyXmuHostData, sumDyXmuShape, &sumDyXmuDeviceAddr, aclDataType::ACL_FLOAT, &sumDyXmu);
  CHECK_RET(ret == ACL_SUCCESS, return ret);
  ret = CreateAclTensor(gradWeightHostData, gradWeightShape, &gradWeightDeviceAddr, aclDataType::ACL_FLOAT, &gradWeight);
  CHECK_RET(ret == ACL_SUCCESS, return ret);
  ret = CreateAclTensor(gradBiasHostData, gradBiasShape, &gradBiasDeviceAddr, aclDataType::ACL_FLOAT, &gradBias);
  CHECK_RET(ret == ACL_SUCCESS, return ret);

  // 3. 调用CANN算子库API
  uint64_t workspaceSize = 0;
  aclOpExecutor* executor;

  // 调用aclnnBatchNormReduceBackward第一段接口
  ret = aclnnBatchNormReduceBackwardGetWorkspaceSize(gradOut, input, mean, invstd, weight,
                                                     inputG, weightG, biasG,
                                                     sumDy, sumDyXmu, gradWeight, gradBias,
                                                     &workspaceSize, &executor);
  CHECK_RET(ret == ACL_SUCCESS, LOG_PRINT("aclnnBatchNormReduceBackwardGetWorkspaceSize failed. ERROR: %d\n", ret); return ret);

  // 根据第一段接口计算出的workspaceSize申请device内存
  void* workspaceAddr = nullptr;
  if (workspaceSize > 0) {
    ret = aclrtMalloc(&workspaceAddr, workspaceSize, ACL_MEM_MALLOC_HUGE_FIRST);
    CHECK_RET(ret == ACL_SUCCESS, LOG_PRINT("allocate workspace failed. ERROR: %d\n", ret); return ret;);
  }

  // 调用aclnnBatchNormReduceBackwardNpuImpl第二段接口
  ret = aclnnBatchNormReduceBackward(workspaceAddr, workspaceSize, executor, stream);
  CHECK_RET(ret == ACL_SUCCESS, LOG_PRINT("aclnnBatchNormReduceBackward failed. ERROR: %d\n", ret); return ret);
  // 4. （固定写法）同步等待任务执行结束
  ret = aclrtSynchronizeStream(stream);
  CHECK_RET(ret == ACL_SUCCESS, LOG_PRINT("aclrtSynchronizeStream failed. ERROR: %d\n", ret); return ret);
  // 5. 获取输出的值，将device侧内存上的结果拷贝至Host侧，需要根据具体API的接口定义修改
  PrintOutResult(sumDyShape, &sumDyDeviceAddr);
  PrintOutResult(sumDyXmuShape, &sumDyXmuDeviceAddr);
  PrintOutResult(gradWeightShape, &gradWeightDeviceAddr);
  PrintOutResult(gradBiasShape, &gradBiasDeviceAddr);

  // 6. 释放aclTensor和aclScalar，需要根据具体API的接口定义修改
  aclDestroyTensor(input);
  aclDestroyTensor(gradOut);
  aclDestroyTensor(mean);
  aclDestroyTensor(invstd);
  aclDestroyTensor(weight);
  aclDestroyTensor(sumDy);
  aclDestroyTensor(sumDyXmu);
  aclDestroyTensor(gradWeight);
  aclDestroyTensor(gradBias);
  return 0;
}
父主题： NN类算子接口
